Geometrical Meaning of Differentiation
It is useful to consider what geometrical meaning can be given to the derivative.
In the first place, any function of \(x\), such, for example, as \(x^2\), or \(\sqrt{x}\), or \(ax+b\), can be plotted as a curve; and nowadays many students are familiar with the process of curve-plotting. Various tools are available for plotting curves, such as graphing calculators, Wolfram Alpha,1 MATLAB, Python, or even Microsoft Excel.
Let \(PQR\), in the next figure, be a portion of a curve plotted with respect to the \(x\) and \(y\) axes. Consider any point \(Q\) on this curve with coordinates \((x,y)\) (i.e. the abscissa of the point is \(x\) and its ordinate is \(y\)).
Now observe how \(y\) changes when \(x\) is varied. If \(x\) is made to increase by a small increment \(dx\), to the right, it will be observed that \(y\) also (in this particular curve) increases by a small increment \(dy\) (because this particular curve happens to be an ascending curve). Then the ratio of \(dy\) to \(dx\) is a measure of the degree to which the curve is sloping up between the two points \(Q\) and \(T\). As a matter of fact, it can be seen on the figure that the curve between \(Q\) and \(T\) has many different slopes, so that we cannot very well speak of the slope of the curve between \(Q\) and \(T\). If, however, \(Q\) and \(T\) are so near each other that the small portion \(QT\) of the curve is practically straight, then it is true to say that the ratio \(\dfrac{dy}{dx}\) is the slope of the curve along \(QT\). The straight line \(QT\) produced on either side touches the curve along the portion \(QT\) only, and if this portion is indefinitely small, the straight line will touch the curve at practically one point only, and be therefore a tangent to the curve.
This tangent to the curve has evidently the same slope as \(QT\), so that \(\boldsymbol{\dfrac{dy}{dx}}\) is the slope of the tangent to the curve at the point \(Q\) for which the value of \(\boldsymbol{\dfrac{dy}{dx}}\) is found.
We have seen that the short expression “the slope of a curve” has no precise meaning, because a curve has so many slopes—in fact, every small portion of a curve has a different slope. “The slope of a curve at a point” is, however, a perfectly defined thing; it is the slope of a very small portion of the curve situated just at that point; and we have seen that this is the same as “the slope of the tangent to the curve at that point.”
The slope of a curve at a point is the slope of the tangent to the curve at that point.
Observe that \(dx\) is a short step to the right, and \(dy\) the corresponding short step upwards. These steps must be considered as short as possible—in fact indefinitely short,—though in diagrams we have to represent them by bits that are not infinitesimally small, otherwise they could not be seen.
We shall hereafter make considerable use of this circumstance that \(\boldsymbol{\dfrac{dy}{dx}}\) represents the slope of the curve at any point.
If a curve is sloping up at \(45^\circ\) at a particular point, as in the next figure, \(dy\) and \(dx\) will be equal, and the value of \(\dfrac{dy}{dx} = 1\).
If the curve slopes up steeper than \(45^\circ\) (next figure), \(\dfrac{dy}{dx}\) will be greater than \(1\).
If the curve slopes up very gently, as in the next figure, \(\dfrac{dy}{dx}\) will be a fraction smaller than \(1\).
For a horizontal line, or a horizontal place in a curve, \(dy=0\), and therefore \(\dfrac{dy}{dx}=0\).
If a curve slopes downward, as in the next figure, \(dy\) will be a step down, and must therefore be reckoned of negative value; hence \(\dfrac{dy}{dx}\) will have negative sign also.
If the “curve” happens to be a straight line, like that in the following figure, the value of \(\dfrac{dy}{dx}\) will be the same at all points along it. In other words its slope is constant.
If a curve is one that turns more upwards as it goes along to the right, the values of \(\dfrac{dy}{dx}\) will become greater and greater with the increasing steepness, as in the following figure.
If a curve is one that gets flatter and flatter as it goes along, the values of \(\dfrac{dy}{dx}\) will become smaller and smaller as the flatter part is reached, as in the next figure.
If a curve first descends, and then goes up again, as in the next figure, presenting a concavity upwards, then clearly \(\dfrac{dy}{dx}\) will first be negative, with diminishing values as the curve flattens, then will be zero at the point where the bottom of the trough of the curve is reached; and from this point onward \(\dfrac{dy}{dx}\) will have positive values that go on increasing. In such a case \(y\) is said to pass by a minimum. The minimum value of \(y\) is not necessarily the smallest value of \(y\), it is that value of \(y\) corresponding to the bottom of the trough; for instance, in the next figure, the value of \(y\) corresponding to the bottom of the trough is \(1\), while \(y\) takes elsewhere values which are smaller than this. The characteristic of a minimum is that \(y\) must increase on either side of it.
Note—For the particular value of \(x\) that makes \(y\) a minimum, the value of \(\dfrac{dy}{dx} = 0\).
If a curve first ascends and then descends, the values of \(\dfrac{dy}{dx}\) will be positive at first; then zero, as the summit is reached; then negative, as the curve slopes downwards, as in the next figure. In this case \(y\) is said to pass by a maximum, but the maximum value of \(y\) is not necessarily the greatest value of \(y\). In the above figure, the maximum of \(y\) is \(2\frac{1}{3}\), but this is by no means the greatest value \(y\) can have at some other point of the curve.
Note—For the particular value of \(x\) that makes \(y\) a maximum, the value of \(\dfrac{dy}{dx}= 0\).
If a curve has the peculiar form of the following figure, the values of \(\dfrac{dy}{dx}\) will always be positive; but there will be one particular place where the slope is least steep, where the value of \(\dfrac{dy}{dx}\) will be a minimum; that is, less than it is at any other part of the curve.
If a curve has the form of the following figure, the value of \(\dfrac{dy}{dx}\) will be negative in the upper part, and positive in the lower part; while at the nose of the curve where it becomes actually perpendicular, the value of \(\dfrac{dy}{dx}\) will be infinitely great.
In summary:
When \(x\) increases
If \(\dfrac{dy}{dx}>0\), \(\qquad y\) increases; the curves ascends to the right.
If \(\dfrac{dy}{dx}<0\), \(\qquad y\) decreases; the curve descends to the right.
Now that we understand that \(\dfrac{dy}{dx}\) measures the steepness of a curve at any point, let us turn to some of the equations which we have already learned how to differentiate.
Example 10.1. As the simplest case take this: \[y=x+b.\]
It is plotted out in the following figure, using equal scales for \(x\) and \(y\). If we put \(x = 0\), then the corresponding ordinate will be \(y = b\); that is to say, the “curve” crosses the \(y\)-axis at the height \(b\). From here it ascends at \(45^\circ\); for whatever values we give to \(x\) to the right, we have an equal \(y\) to ascend. The line has a gradient of \(1\) in \(1\).
Now differentiate \(y = x+b\), by the rules we have already learned, and we get \(\dfrac{dy}{dx} = 1\).
The slope of the line is such that for every little step \(dx\) to the right, we go an equal little step \(dy\) upward. And this slope is constant—always the same slope.
Example 10.2. Take another case: \[y = ax+b.\] We know that this curve, like the preceding one, will start from a height \(b\) on the \(y\)-axis. But before we draw the curve, let us find its slope by differentiating; which gives \(\dfrac{dy}{dx} = a\). The slope will be constant, at an angle, the tangent of which is here called \(a\). Let us assign to \(a\) some numerical value—say \(\frac{1}{3}\). Then we must give it such a slope that it ascends \(1\) in \(3\); or \(dx\) will be \(3\) times as great as \(dy\); as magnified in the following figure.
So, draw the line in the next figure at this slope.
Now for a slightly harder case.
Example 10.3. Let \[y= ax^2 + b.\]
Again the curve will start on the \(y\)-axis at a height \(b\) above the origin.
Now differentiate. [If you have forgotten, turn back; or, rather, don’t turn back, but think out the differentiation.] \[\frac{dy}{dx} = 2ax.\]
This shows that the steepness will not be constant: it increases as \(x\) increases. At the starting point \(P\), where \(x = 0\), the curve (next figure) has no steepness—that is, it is level. On the left of the origin, where \(x\) has negative values, \(\dfrac{dy}{dx}\) will also have negative values, or will descend from left to right, as in the Figure.
Let us illustrate this by working out a particular instance. Taking the equation \[y = \frac{1}{4}x^2 + 3,\] and differentiating it, we get \[\dfrac{dy}{dx} = \frac{1}{2}x.\] Now assign a few successive values, say from \(0\) to \(5\), to \(x\); and calculate the corresponding values of \(y\) by the first equation; and of \(\dfrac{dy}{dx}\) from the second equation. Tabulating results, we have:
| \(x\) | \(0\) | \(1\) | \(2\) | \(3\) | \(4\) | \(5\) |
|---|---|---|---|---|---|---|
| \(y\) | \(3\) | \(3\frac{1}{4}\) | \(4\) | \(5\frac{1}{4}\) | \(7\) | \(9\frac{1}{4}\) |
| \(\dfrac{dy}{dx}\) | \(0\) | \(\frac{1}{2}\) | \(1\) | \(1\frac{1}{2}\) | \(2\) | \(2\frac{1}{2}\) |
Then plot them out in two curves, Fig. 10.18 and Fig. 10.19; in Fig. 10.18 plotting the values of \(y\) against those of \(x\) and in Fig. 10.19 those of \(\dfrac{dy}{dx}\) against those of \(x\). For any assigned value of \(x\), the height of the ordinate in the second curve is proportional to the slope of the first curve.
If a curve comes to a sudden cusp, as in the following figure, the slope at that point suddenly changes from a slope upward to a slope downward. In that case \(\dfrac{dy}{dx}\) will clearly undergo an abrupt change from a positive to a negative value.
The following examples show further applications of the principles just explained.
Example 10.4. (a) Find the slope of the tangent to the curve \[y = \frac{1}{2x} + 3,\] at the point where \(x = -1\). (b) Find the angle which this tangent makes with the curve \(y = 2x^2 + 2\).
Solution. (a) The slope of the tangent is the slope of the curve at the point where they touch one another; that is, it is the \(\dfrac{dy}{dx}\) of the curve for that point. Here \(\dfrac{dy}{dx} = -\dfrac{1}{2x^2}\) and for \(x = -1\), \(\dfrac{dy}{dx} = -\dfrac{1}{2}\), which is the slope of the tangent and of the curve at that point. The tangent, being a straight line, has for equation \(y = ax + b\), and its slope is \(\dfrac{dy}{dx} = a\), hence \(a = -\dfrac{1}{2}\). Also if \(x= -1\), \(y = \dfrac{1}{2(-1)} + 3 = 2\frac{1}{2}\); and as the tangent passes by this point, the coordinates of the point must satisfy the equation of the tangent, namely \[y = -\dfrac{1}{2} x + b,\] so that \(2\frac{1}{2} = -\dfrac{1}{2} \times (-1) + b\) and \(b = 2\); the equation of the tangent is therefore \(y = -\dfrac{1}{2} x + 2\) (see the following figure).
(b) Now, when two curves meet, the intersection being a point common to both curves, its coordinates must satisfy the equation of each one of the two curves; that is, it must be a solution of the system of simultaneous equations formed by coupling together the equations of the curves. Here the curves meet one another at points given by the solution of \[\left\{ \begin{align} y &= 2x^2 + 2, \\ y &= -\frac{1}{2} x + 2 \quad\text{or}\quad 2x^2 + 2 = -\frac{1}{2} x + 2; \end{align} \right.\]
that is, \[x(2x + \frac{1}{2}) = 0.\]
This equation has for its solutions \(x = 0\) and \(x = -\frac{1}{4}\) (see the next figure). The slope of the curve \(y = 2x^2 + 2\) at any point is \[\dfrac{dy}{dx} = 4x.\]
For the point where \(x = 0\), this slope is zero; the curve is horizontal. For the point where \[x = -\dfrac{1}{4},\quad \dfrac{dy}{dx} = -1;\] hence the curve at that point slopes downwards to the right at such an angle \(\theta\) with the horizontal that \(\tan \theta = 1\); that is, at \(45^\circ\) to the horizontal.
The slope of the straight line is \(-\frac{1}{2}\); that is, it slopes downwards to the right and makes with the horizontal an angle \(\phi\) such that \(\tan \phi = \frac{1}{2}\); that is, an angle of \(26^\circ~34'\). It follows that at the first point the curve cuts the straight line at an angle of \(26^\circ~34'\), while at the second it cuts it at an angle of \(45^\circ - 26^\circ~34' = 18^\circ~26'\) (see the next figure).
Example 10.5. A straight line is to be drawn, through a point whose coordinates are \(x = 2\), \(y = -1\), as tangent to the curve \(y = x^2 - 5x + 6\). Find the coordinates of the point of contact.
Note.—-the point \((2,-1)\) does not lie on the curve \(y=x^2-5x+6\).
Solution. The slope of the tangent must be the same as the \(\dfrac{dy}{dx}\) of the curve; that is, \(2x - 5\).
The equation of the straight line is \(y = ax + b\), and as it is satisfied for the values \(x = 2\), \(y = -1\), then \(-1 = a\times2 + b\); also, its \(\dfrac{dy}{dx} = a = 2x - 5\) [since \(y=ax+b\) is the tangent line, its slope, \(a\), must be the same as \(\dfrac{d(x^2-5x+6)}{dx}\)].
The \(x\) and the \(y\) of the point of contact must also satisfy both the equation of the tangent and the equation of the curve.
We have then \[\left\{\begin{align} y &= x^2 - 5x + 6, &&\text{(i)} \\ y &= ax + b, &&\text{(ii)} \\ -1 &= 2a + b, &&\text{(iii)} \\ a &= 2x - 5, &&\text{(iv)} \end{align}\right.\] four equations in \(a\), \(b\), \(x\), \(y\).
Equations (i) and (ii) give \(x^2 - 5x + 6 = ax+b\).
Replacing \(a\) and \(b\) by their value in this, we get \[x^2 - 5x + 6 = (2x - 5)x - 1 - 2(2x - 5),\] which simplifies to \(x^2 - 4x + 3 = 0\), the solutions of which are: \(x = 3\) and \(x = 1\). Replacing in (i), we get \(y = 0\) and \(y = 2\) respectively; the two points of contact are then \(x = 1\), \(y = 2\), and \(x = 3\), \(y = 0\) (see the following figure).
Note.—In all exercises dealing with curves, students will find it extremely instructive to verify the deductions obtained by actually plotting the curves.
Exercises
Exercise 10.1. Plot the curve \(y = \dfrac{3}{4} x^2 - 5\), using equal scales for \(x\) and \(y\). Measure at points corresponding to different values of \(x\), the angle of its slope.
Find, by differentiating the equation, the expression for slope; and see, from a Table of Natural Tangents, whether this agrees with the measured angle.
Solution
\[y=\frac{3}{4} x^2 - 5 \Rightarrow \frac{dy}{dx}=\frac{3}{2}x\]
When \(x=-3\), \(\dfrac{dy}{dx}=-\dfrac{9}{2}\)
from the graph: slope of the tangent line \(=\dfrac{-9}{2}=-4.5\). They agree.
When \(x=-2\), \(\dfrac{dy}{dx}=-3\)
from the graph: slope of the tangent line \(=\dfrac{-6}{2}=-3\). They agree.
When \(x=-1\), \(\dfrac{dy}{dx}=-\dfrac{3}{2}\)
from the graph: slope of the tangent line \(=\dfrac{-3}{2}=-1.5\). They agree.
When \(x=0\), \(\dfrac{dy}{dx}=0\)
from the graph: the tangent line is horizontal. Thus its slope is zero. They agree.
When \(x=1\), \(\dfrac{dy}{dx}=\dfrac{3}{2}\)
from the graph: slope of the tangent line \(=\dfrac{3}{2}=1.5\). They agree.
When \(x=2\), \(\dfrac{dy}{dx}=3\)
from the graph: slope of the tangent line \(=\dfrac{6}{2}=3\). They agree.
When \(x=3\), \(\dfrac{dy}{dx}=\dfrac{9}{2}\)
from the graph: slope of the tangent line \(=\dfrac{9}{2}=4.5\). They agree.
Exercise 10.2. Find what will be the slope of the curve \[y = 0.12x^3 - 2,\] at the particular point with \(x=2\).
Answer
\(1.44\).
Solution
\[\begin{align} & y=0.12 x^{3}-2 \\ & \frac{d y}{d x}=3 \times 0.12 x^{2}=0.36 x^{2} \end{align}\]
When \(x=2, \quad \dfrac{d y}{d x}=1.44\).
Hence, the slope of the curve at the point with \(x=2\) is \(1.44\).
Exercise 10.3. If \(y = (x - a)(x - b)\), show that at the particular point of the curve where \(\dfrac{dy}{dx} = 0\), \(x\) will have the value \(\frac{1}{2} (a + b)\).
Solution
\[y=(x-a)(x-b)\] Using the Product Rule: \[\begin{align} \frac{d y}{d x}&=(x-b)+(x-a)\\ &=2 x-a-b \end{align}\] Setting \(\dfrac{dy}{dx}=0\), we get \[x=\frac{a+b}{2}.\]
Exercise 10.4. Find the \(\dfrac{dy}{dx}\) of the equation \(y = x^3 + 3x\); and calculate the numerical values of \(\dfrac{dy}{dx}\) for the points corresponding to \(x = 0\), \(x = \frac{1}{2}\), \(x = 1\), \(x = 2\).
Answer
\(\dfrac{dy}{dx} = 3x^2 + 3\); and the numerical values are: \(3\), \(3 \frac{3}{4}\), \(6\), and \(15\).
Solution
\[\begin{align} & y=x^{3}+3 x \\ & \frac{d y}{d x}=3 x^{2}+3 \end{align}\]
When \(x=0\), \(\dfrac{dy}{dx}=3\).
When \(x=0\), \(\dfrac{dy}{dx}=3+\frac{3}{4}=3\frac{3}{4}=3.75\).
When \(x=1\), \(\dfrac{dy}{dx}=6\).
When \(x=2\), \(\dfrac{dy}{dx}=15\).
Exercise 10.5. In the curve to which the equation is \(x^2 + y^2 = 4\), find the values of \(x\) at those points where the slope \({} = 1\).
Answer
\(\pm \sqrt{2}\).
Solution
\[x^{2}+y^{2}=4\] Solving for \(y\): \[y= \pm \sqrt{4-x^{2}}= \pm\left(4-x^{2}\right)^{\frac{1}{2}}\]
To find \(\dfrac{dy}{dx}\), let \(u=4-x^{2}\). Then \(y= \pm u^{\frac{1}{2}}\) and
\[\begin{align} \frac{d y}{d x} & =\frac{d y}{d u} \cdot \frac{d u}{d x} \\ & = \pm \frac{1}{2} u^{-\frac{1}{2}}(-2 x) \\ & = \pm \frac{-x}{\sqrt{4-x^{2}}}=\mp \frac{x}{\sqrt{4-x^{2}}} \\ \frac{d y}{d x} & =1 \Rightarrow \mp \frac{x}{\sqrt{4-x^{2}}}=1 \end{align}\]
First consider the \(-\) sign:
\[-x=\sqrt{4-x^{2}}\]
We must have \(x \leq 0\) because the right-hand side is nonnegative.
\[\begin{align} & x^{2}=4-x^{2} \\ & 2 x^{2}=4 \\ & x= \pm \sqrt{2} \end{align}\] Only \(x=-\sqrt{2}\) is acceptable.
When \(x=-\sqrt{2}\):
\[y=+\sqrt{4-x^{2}}=+\sqrt{2}\]
Now consider \(+\) sign:
\[x=\sqrt{4-x^{2}}\] We must have \(x \geq 0\) because the right-hand side is always nonnegative
\[\begin{align} x^{2} & =4-x^{2} \\ 2 x^{2} & =4 \\ x & = \pm \sqrt{2} \end{align}\] Only \(x=+\sqrt{2}\) is acceptable.
When \(x=+\sqrt{2}\): \[y=-\sqrt{4-x^{2}}=-\sqrt{2}\]
Therefore at two points \((-\sqrt{2},+\sqrt{2})\) and \((+\sqrt{2},-\sqrt{2})\), the slope of the curve is 1.
Exercise 10.6. Find the slope, at any point, of the curve whose equation is \(\dfrac{x^2 }{3^2} + \dfrac{y^2}{2^2} = 1\); and give the numerical value of the slope at the place where \(x = 0\), and at that where \(x = 1\).
Answer
\(\dfrac{dy}{dx} = - \dfrac{4}{9} \dfrac{x}{y}\). Slope is zero where \(x = 0\); and is \(\mp \dfrac{1}{3 \sqrt{2}}\) where \(x = 1\).
Solution
\[\frac{x^{2}}{9}+\frac{y^{2}}{4}=1\]
Method 1: Using the chain Rule
\[\begin{align} & \frac{d\left(\frac{x^{2}}{9}\right)}{d x}+\frac{d\left(\frac{y^{2}}{4}\right)}{d x}=1 \\ & \frac{1}{9} 2 x+\frac{1}{4} 2 y \cdot \frac{d y}{d x}=0 \\ \end{align}\] Hence \[\frac{d y}{d x}=-\frac{\frac{1}{9} x}{\frac{y}{4}}=-\frac{4}{9} \frac{x}{y}\] or \[\begin{align} \frac{d y}{d x} & =-\frac{4}{9} \frac{x}{ \pm 2 \sqrt{1-\frac{x^{2}}{9}}} \\ & =\mp \frac{2}{3} \frac{x}{\sqrt{9-x^{2}}} \end{align}\]
Method 2: We can achieve the same result if we solve \[\frac{x^{2}}{9}+\frac{y^{2}}{4}=1\] for \(y\). That is
\[\begin{align} y & = \pm 2 \sqrt{1-\frac{x^{2}}{9}} \\ & = \pm 2\left(1-\frac{x^{2}}{9}\right)^{\frac{1}{2}} \end{align}\]
To find \(\frac{d y}{d x}\), let \(x=1-\frac{x^{2}}{9}\). Then \(y= \pm 2 u^{\frac{1}{2}}\) and \[\begin{align} \frac{d y}{d x} & =\frac{d y}{d u} \cdot \frac{d u}{d x} \\ & = \pm \frac{1}{2} u^{-\frac{1}{2}}\cdot(-2 x) \\ & = \pm \frac{-x}{\sqrt{4-x^2}}=\mp \frac{x}{\sqrt{4-x^2}} \end{align}\]
When \(x=0, \quad \dfrac{d y}{d x}=0\)
When \(x=1, \quad \dfrac{d y}{d x}=\mp \dfrac{2}{3 \sqrt{8}}=\mp \dfrac{1}{3 \sqrt{2}}.\) To be more specific, when \(x=1\), if \(y>0\), then \(\dfrac{dy}{dx}=-\dfrac{1}{3\sqrt{2}}\), and if \(y<0\), then \(\dfrac{dy}{dx}=+\dfrac{1}{3\sqrt{2}}\).
Exercise 10.7. The equation of a tangent to the curve \(y = 5 - 2x + 0.5x^3\), being of the form \(y = mx + n\), where \(m\) and \(n\) are constants, find the value of \(m\) and \(n\) if the point where the tangent touches the curve has \(x=2\) for abscissa.
Answer
\(m = 4\), \(n = -3\).
Solution
\[y=5-2 x+0.5 x^{3}\]
\[\frac{d y}{d x}=-2+1.5 x^{2}\]
When \(x=2, \quad \frac{d y}{d x}=4\).
When \(x=2, \quad y=5\).
The equation of the line with slope 4 passing through \((2,5)\) is \[y-5=4(x-2)\] or \[y=4 x-3\] Therefore,
\[m=4 \quad \text { and }\quad n=-3\]
Exercise 10.8. At what angle do the two curves \[y = 3.5x^2 + 2 \quad \text{and} \quad y = x^2 - 5x + 9.5\] cut one another?2
Answer
Intersections at \(x = 1\), \(x = -3\). Angles \(153^\circ\;26'\), \(2^\circ\;28'\).
Solution
First, we need to calculate, at what point these two curves intersect:
Setting the equations of the two curves equal:
\[3.5 x^{2}+2=x^{2}-5 x+9.5\] \[\Rightarrow 2.5 x^{2}+5 x-7.5=0\] \[\begin{align} \Rightarrow \quad x&=\frac{-5 \pm \sqrt{25+4 \times 2.5 \times 7.5}}{5} \\ &=\frac{-5 \pm 10}{5} \end{align}\]
Therefore, these two curves intersect at \(x=-3\) and \(x=1\).
Now we need to find the slopes of these two curves at \(x=3\) and \(x=1\).
\[\begin{align} & y=3.5 x^{2}+2 \Rightarrow \frac{d y}{d x}=7 x \\ & y=x^{2}-5 x+9.5 \Rightarrow \frac{d y}{d x}=2 x-5 \end{align}\]
When \(x=-3\), the slope of the first curve is \(-21\) and the slope of the second curve is \(-11\).
That is \(\tan \alpha=-21\) and \(\tan \beta=-11\), where \(\alpha\) and \(\beta\) are the angles that their tangents makes with the positive direction of the \(x\)-axis.
\[\begin{gathered} \tan \alpha=-21 \Rightarrow \alpha=\arctan (-21) \approx-1.52 ~\mathrm{rad} \\ \text { or }\quad \alpha \approx-87.27^{\circ} \\ \tan \beta=-11 \Rightarrow \beta=\arctan (-11) \approx-1.48~ \mathrm{rad}\\ \text { or }\quad \beta \approx-84.81^{\circ} \end{gathered}\] Therefore, the angle between them when \(x=3\) is \(87.27-84.81=2.47^{\circ}\) or
\[\text { angle }=2^{\circ}+0.47 \times 60^{\prime} \approx 2^{\circ} 28^{\prime}\]
Similarly, when \(x=1\), the slope of the first curve is \(7\). \[\tan \alpha=7 \Rightarrow \alpha=\arctan 7 \approx 1.429~\mathrm{rad}\] or \[\alpha \approx 81.87^\circ\]
The slope of the second curve is \(-3\). \[\tan \beta=-3 \Rightarrow \beta=\arctan (-3) \approx-1.249~\mathrm{rad}\] or \[\beta \approx-71.57^{\circ}\] Therefore, the angle between them when \(x=1\) is \(81.87+71.57=153.44\) or \[\text { angle }=153^{\circ}+0.44 \times 60^{\prime} \approx 153^{\circ} 26^{\prime}\]
Exercise 10.9. Tangents to the curve \(y = \pm \sqrt{25-x^2}\) are drawn at points for which \(x = 3\) and \(x = 4\). Find the coordinates of the point of intersection of the tangents and their mutual inclination.
Answer
Intersection at \(x =\frac{25}{7}\approx 3.57\), \(y=\frac{25}{7}\approx 3.57\). Angle \(16^\circ\;16'\).
Solution
Let’s consider \(y>0\). The case where \(y<0\) can then be obtained by symmetry. \[\begin{align} y & =+\sqrt{25-x^{2}} \\ \frac{d y}{d x} & =\frac{-2 x}{2 \sqrt{25-x^{2}}}=\frac{-x}{\sqrt{25-x^{2}}} \end{align}\]
When \(x=3, \quad \dfrac{d y}{d x}=\frac{-3}{4}\).
When \(x=3,\quad y=4\).
The equation of the tangent line at \(x=3\) and \(y>0\) is then \[y-4=-\frac{3}{4}(x-3)\] or \[y=-\frac{3}{4} x+\frac{25}{4}\]
When \(x=4,\quad \dfrac{d y}{d x}=-\frac{4}{3}\).
When \(x=4,\quad y=3\).
The equation of the tangent line is
\[y-3=-\frac{4}{3}(x-4)\] or \[y=-\frac{4}{3} x+\frac{25}{3}\]
To find the intersection of the tangent lines at \(x=3\) and \(x=4\) (for \(y>0\)), we set the equations of these two tangent lines equal:
\[\begin{align} -\frac{3}{4} x+\frac{25}{4} & =-\frac{4}{3} x+\frac{25}{3} \\ \Rightarrow\ \frac{7}{12} x & =\frac{25}{12} \\ \Rightarrow\ x & =\frac{25}{7} \approx 3.57 \end{align}\]
When \(x=\frac{25}{7}, y=-\frac{3}{4} \times \frac{25}{7}+\frac{25}{4}=\frac{25}{7} \approx 3.57\). Therefore, these two tangent line intersect at the point \((\frac{25}{7},\frac{25}{7})\approx (3.57, 3.57)\).
Since the slope of the first tangent line is \(-3/4\), the slope of the angle that it makes with the positive \(x\)-axis is \[\alpha=\arctan \left(-\frac{3}{4}\right) \approx-0.643 \text { rad }\] or \[\alpha \approx-36.87^{\circ}\] Similarly, the slope of the second tangent line is \(-\frac{4}{3}\) and hence the angle that it makes with the positive \(x\)-axis is \[\beta=\arctan\left(-\frac{4}{3}\right)\approx -0.927~\text{rad}\] or \[\beta\approx -53.13^\circ\]
Therefore, the angle between them \(53.13^{\circ}-36.87^{\circ}=16.26^{\circ}\) or \[16^{\circ}+0.26 \times 60^{\prime} \approx 16^{\circ} 16^{\prime}\]
Exercise 10.10. A straight line \(y = 2x - b\) touches a curve \(y = 3x^2 + 2\) at one point. What are the coordinates of the point of contact, and what is the value of \(b\)?
Answer
\(x = \frac{1}{3}\), \(y = 2 \frac{1}{3}\), \(b = -\frac{5}{3}\).
Solution
The slope of \(y=2 x-b\) is 2 . We have to find at what point the slope of the tangent to \(y=3 x^{2}+2\) is \(2\), we differentiate \(y=3x^2+2\)
\[\frac{d y}{d x}=6 x=2 \Rightarrow x=\frac{1}{3}\] When \(x=\frac{1}{3}, \quad y=3 \times \frac{1}{3^{2}}+2=\frac{7}{3}\).
Therefore, the point of contact is \(\left(\frac{1}{3}, \frac{7}{3}\right)\).
The equation of the tangent line at this point is hence \[y-\frac{7}{3}=2\left(x-\frac{1}{3}\right)\] or \[y=2 x+\frac{5}{3}\]
Therefore \[b=-\frac{5}{3}\]
